375hp CS turbo

[Justin@Freektune]

Finally had a chance to play with one on the Dyno. Car is a 2012 with 21k miles, HTP 3.0 intake, CS TMIC, catted TBE, and aem meth kit running a 500cc nozzle and straight blue washer fluid (30% methanol) we weren't trying to get crazy with power as he plans to stay stock block. Ended up with 375hp/360tq. Then we went to the track later that night. After I made a couple passes in my car, I took his for a rip. On street tires and first pass, it went 13.1@113 hitting the limiter before the finish. So we will raise the rev limiter to 7k, and she should walk right into the 12s on street tires and a mediocre 60ft



Sent from my iPhone using Tapatalk

[Koke382]

Nice. I still want to see one maxed out.

Sent from my LGLS991 using Tapatalk

[Justin@Freektune]

Originally Posted by Koke382 Nice. I still want to see one maxed out. Sent from my LGLS991 using Tapatalk

It would certainly clear 400 if pushed a little harder

[Easter Bunny]

That car was fucking flying for
turbo
downpipe
intake
TMIC
meth

[Justin@Freektune]

Originally Posted by Easter Bunny That car was fucking flying for turbo downpipe intake TMIC meth

You can't forget the turbo mentioned in the title. haha

[Easter Bunny]

Originally Posted by Easter Bunny That car was fucking flying for turbo downpipe intake TMIC meth

Originally Posted by Justin@Freektune You can't forget the turbo mentioned in the title. haha

i didn't

these results from a "drop-in" turbo are outstanding.

[Justin@Freektune]

Originally Posted by Easter Bunny i didn't these results from a "drop-in" turbo are outstanding.

oops, skipped right over the turbo part. My apologies. haha

[Atomic41]

What you think about the turbo ??? vs BNR S3 ...

Performance/$ is it a good turbo ???

K04 tuned (6200rpm max ???)
so the CS Turbo you can push it to 7000rpm (is it the max ??)

Thanks for your help

[JgamB]

Originally Posted by Atomic41 What you think about the turbo ??? vs BNR S3 ... Performance/$ is it a good turbo ??? K04 tuned (6200rpm max ???) so the CS Turbo you can push it to 7000rpm (is it the max ??) Thanks for your help

Full weight 2800 DA passes on the BNR S3 25% E85. I did not have meth at this point, but I did ask Justin to kindly increase my rev limit to 7.2K - which is probably most of the ~4-5mph trap difference. Either turbo will make the car a helluva lot of fun with that Freektune and some alcohol.

[doctavus]

Using e85 or 93?

Assuming 93 and using the 30% methanol.

[atvfreek]

Originally Posted by Atomic41 What you think about the turbo ??? vs BNR S3 ... Performance/$ is it a good turbo ??? K04 tuned (6200rpm max ???) so the CS Turbo you can push it to 7000rpm (is it the max ??) Thanks for your help

I would say it spools slightly slower than the s3 but has slightly more flow up top. At the end of the day it will make pretty similar power though.

You can run it out to 7k. Although power won't be climbing. It should stay pretty flat or just fall slightly.

Originally Posted by doctavus Using e85 or 93? Assuming 93 and using the 30% methanol.

93 in gas tank. No e85, and 30% methanol via water meth injection


Sent from my iPhone using Tapatalk

[atvfreek]

Gotta love Tapatalk. Thing just decides whatever account it chooses to post from. Lol.


Sent from my iPhone using Tapatalk

[shadesofgray19]

What is target boost?

[speedfreak44]

How much of this is due to the additional fueling vs just DI on 93?

[JgamB]

~45hp difference on my 93 vs E85 tune. I try not to run it at all - not just because it's slow, but because I'd rather be worried about running out of IDC instead of plinking off knock limits.

[speedfreak44]

I like to do my tunes with straight 93 then I add 1 gallon E85 per tank. I keep looking at this turbo it is a great performer I just wish it could be clocked

[Code Monkey]

^ Based on Justin's comment about a slightly slower spool, I would pick a BNR.

[aromig]

Originally Posted by Code Monkey ^ Based on Justin's comment about a slightly slower spool, I would pick a BNR.

Those of us with lowly front wheelers though, might be better served with the CS.

[speedfreak44]

What was max psi? And does this turbo hold boost to 7k no issue?

[CWP_MS3]

I assume the 326 was a baseline without meth...? Or is that a different gear?

[atvfreek]

Originally Posted by CWP_MS3 I assume the 326 was a baseline without meth...? Or is that a different gear?

That was just a base tune I had on the car to get to the Dyno


Sent from my iPhone using Tapatalk

[CWP_MS3]

Ahhhhh. Got it. Makes sense. I didn't know if it was a straight 93 pull without meth to get an idea of what the turbo can do with itself. I was gonna say, IIRC, a BNR is about 330ish.

[AwAfrican]

Justin you are the man must say I'm impressed with the cs turbo so far would like to know what it maxed out is though. It's time will once I'm sure

sent via tapafail!

[knocturnal]

It was either this turbo or a new Gaming laptop and i think you have convinced me on what decision i should make...

[EmPeEs6]

Hard to believe that this one should outperform a GT28-size turbo like the S3 which has already proven to be capable of making more than 400 whp more than once.
Does anybody know the exact housing/wheel specs of the BNR so that one could compare to the corresponding data CS published on their hp? However I still doubt the 50 lbs/min assertion...
@Justin: Do you think/know that the CS turbo is as efficient at 24/25 psi and high revs as the S3, and which one flows better beyond 6k?

[GCPhotographers]

Originally Posted by Justin@Freektune Finally had a chance to play with one on the Dyno. Car is a 2012 with 21k miles, HTP 3.0 intake, CS TMIC, catted TBE, and aem meth kit running a 500cc nozzle and straight blue washer fluid (30% methanol) we weren't trying to get crazy with power as he plans to stay stock block. Ended up with 375hp/360tq. Then we went to the track later that night. After I made a couple passes in my car, I took his for a rip. On street tires and first pass, it went 13.1@113 hitting the limiter before the finish. So we will raise the rev limiter to 7k, and she should walk right into the 12s on street tires and a mediocre 60ft

Should I be jealous or patient...lol
This is some good shit. Check your email when possible. I want to go faster.

[taf0422]

Originally Posted by GCPhotographers Should I be jealous or patient...lol This is some good shit. Check your email when possible. I want to go faster.

Lol. Dudes on vacation.

[GCPhotographers]

Originally Posted by taf0422 Lol. Dudes on vacation.

I know I know... until the 27th

[aromig]

Originally Posted by taf0422 Lol. Dudes on vacation.

Originally Posted by GCPhotographers I know I know... until the 27th

I for one am hoping he's having a hell of a good time wherever he's at, and not checking a single damn email while gone. For all he does here, he deserves some 100% decompression time. And yes, my nose is brown as fuck. It's all good though, it matches my lips.
